It can freely match the measurement items according to the user's requirements; the whole machine adopts the integrated mold design, the appearance of fashion; application of the latest touch-screen menu-type operating technology, the instrument to achieve practical intelligence features, with acid and alkali resistance, corrosion resistance and other characteristics.
Online Message
Features
Features
Technical Specifications
Standard Configuration
Data download
-Accurately determine COD, ammonia nitrogen, total phosphor, chroma, turbidity, PH, DO, and two heavy metals (optional) indicators in various water bodies
-At the same time support colorimetric and colorimetric tube two colorimetric methods
-7-inch full touch color screen, Chinese menu
-Simple operation, automatic switching of measurement items, customized measurement items according to user requirements
-Memory 100 curves, 15 standard curves, 85 expansion curves can be freely applied under different conditions, different waste water and other conditions
-Temperature setting room temperature ~ 200 °C, the user can adjust according to need, more compatible
-The instrument can calculate the storage curve according to the standard sample
-Built-in printer can print current data, query and print historical data
-USB interface, connect the computer to the host operation, automatically generate a chart (optional)
-Cold light source, narrow band interference, light source lifetime up to 100,000 hours
-Digestion power automatically adjusts with the load quantity, intelligent constant temperature control, delay protection
-Temperature, time can be adjusted and saved
-First domestic rear-mounted splitter technology to avoid external light interference and test data is more stable and reliable
Measurement items | COD/ammonia nitrogen/total phosphor/color/turbidity/PH/DO/two heavy metals (optional) |
Display method | 7 inch full touch color screen |
Measuring range | COD: 5-6000mg/L (segment) |
measurement accuracy | ≤±8% PH：±0.02 DO：±0.3mg/L |
Wavelength range | 400-750nm |
Number of curves | 100 |
Storing data | 5 million |
Repeatability | ≤±5% |
Batch volume | 6/9/12/16/20/24/25/30/36/56/lot |
Color comparison | Colorimetric and colorimetric tubes |
Anti-chlorine interference | {cl-}＜1200mg/l；{cl-}＜4000mg/l |
Light source life | 100,000 hours |
Optical stability | ≤0.001A/10min |
Temperature control range | Room temperature -200°C |
Digestion temperature | 165/123±0.5℃ |
Digestion time | 10/30 minutes |
Product Size | 400*300*180mm |
Working power | AC/220V±10%/50Hz |
Total Weight | 5kg |
Intelligent digestion device, test tube rack, water cooling rack, special solid reagents, special reaction tubes, cuvette holders, semi-automatic dosing devices, etc.
